Applications
Fits Strange 2011 & Newer Bolt-In Housings Only !
For OEM Housings – See S5280RS
Buick – Rear R/H Side
1971-1973 Centurion
1973-1981 Century
1971-1984 Electra
1982-1987 Grand National
1971-1985 Lesabre
1973-1987 Regal
1971-1978 Riviera
1964-1972 Skylark (Except Sport Wagon)
1964-1972 Special (Except Estate Wagon)
Chevrolet – Rear R/H Side
1971-1996 Caprice
1964-1983 Chevelle / Malibu
1968-1985 El Camino
1970-1988 Monte Carlo
Pontiac – Rear R/H Side
1971-1986 Pontiac Bonneville
1971-1981 Catalina
1973-1980 Grand Am
1963-1964 Grand Prix
1969-1987 Grand Prix
1964-1973 GTO
1964-1979 Lemans / Tempest
1982-1983 Lemans / Tempest
Note
For OEM housings – See S5280LS / S5280RS
Description
Rear Single Adjustable Coil-Over Shock
Right hand side
For Left Hand Side – See S5280L
Coil-Over Benefits
• Compact & lightweight
• Allows adjustments to ride height
• Wide range of spring rates available
Soft Settings
For Drag Racing
Allows more downward force applied to the rear tires
Medium Settings
For Performance Street
Enhances handling & cornering characteristics
Stiff Settings
For Road Racing
Provides very aggressive control over body roll
Rotating Knob Clockwise Stiffens Valving
Dimension A
20.53″ Extended / 13.32 Compressed
Features
• Lightweight aluminum body
• 10 extension settings
• Provides a wide range of control
• Easily accessible external adjustment knob
• Allows quick changes for varying conditions
• Custom valving available upon request
• Ability to be rebuilt or revalved
Adjustable Lower Mount
• 6 positions provide 1.875″ of adjustment
• Allows ride height adjustment without altering spring seat position
• Change location of bump & rebound in relation to ride height
Includes
– Upper & lower spring seats
– Lower seat jam nut
– Upper t-bar with spherical bearing
– Lower spherical ball bearing
– Adjustable lower mounting bracket – Drilling required
– Mounting hardware
Spring – Sold Separately
Recommendation
14″ x 2.5″ ID spring
125 lbs
Consult your chassis builder for their suggestion
Related Components
Double adjustable………………. S5080L / S5080R
Springs
14″ 125 lbs……………………. SP14125
Spring seat bearing kit…………. S1409
Adjuster wrench………………… S1413
